Energy Saving Compact Powder Pressing Machine Alloy Steel Convenient Maintenance

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Lisen
Certification: BV
Model Number: LS25T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Wooden case
Delivery Time: 35-65 working days
Payment Terms: TT, LC
Supply Ability: 20000/Year
  • Detail Information
  • Product Description

Detail Information

Working Pressure: ≤25T Filling Depth: 150mm
Product Name: Watercolors Powder Press Machine Application: Tablet Press
Product Mold: Multi-cavity Mould Apply To Shape: Round,square,or Special-shaped
Standard: BV Type: Hydraulic Tablet Press
High Light:

compact powder pressing machine


powder compaction machine

Product Description

Energy Saving Compact Powder Pressing Machine Alloy Steel Convenient Maintenance


Small Automatic Rotary Tablet Press Machine is a single press type, continuous automatic tablet press for pressing granular raw materials into tablets. It is used for small scale production.



1.The machine is compliance with the GMP requirement on the production of pharmaceuticals.

2.The compression parts is entirely separated from the driving mechanism.

3.The compression area is enclosed with transparent organic glass. To prevent contaminates. The compression area can be specially treated. All surface being smooth and easy to clean.

4.The mechanical buffer unit will prevent punches and apparatus from overload damage.


Technical Parameters:

Production Capacity4-6molds/min(the actual speed according to product process requirement)
Working Pressure≤25T(can be bidirectional compress)
Working StrokeUp stroke≤250mm,Down strokes≤150mm(1. step-less adjustment 2. Customized based on customer’s request. )
Filling Depth150mm(1. step-less adjustment 2. Customized based on customer’s request. )
Product MouldCustomized according to the tablet features(Multi-cavity Mould)
Apply to ShapeRound, square, or special-shaped(suitable for a variety of shapes)
Motor Power5. 5kw 7. 5kw(Servo)
Weight&SizeApproximately:1600kg 1800mm*850mm*1800mm(L*W*H)

Energy Saving Compact Powder Pressing Machine Alloy Steel Convenient Maintenance 0

Descriptions and Advantage:

  1. Fully CNC Control Design

Each action can be set separately. Special material tablet forming can be solved by precise control and flexible technology.

  1. Fully Intelligent Operation Design

Production debugging is operated through PLC touch screen, which can cut the cumbersome process in great scope and make the operation more easily.

  1. Fully-automatic Material Filling Design

The filling method and dosage can be intelligently controlled, rapidly and stably, which can save much time and labor.

  1. Isolated Hydraulic Station Design

Oil cylinder working area and mechanical working area are Mutual independence, preventing oil pollution.

  1. Reasonable Structure Design
  1. energy saving and environmental protection
  2. small space occupation
  3. superior performance
  4. simple operation
  5. easy maintenance and so on.

Technology and Advantage:

  1. Demoulding Protection

Protecting the compressed tablet well,which are damaged by improper mould forces in the course of production.

  1. Uniform Density

Uniform density of the compressed tablet can be ensured through special technology.

  1. Different layer different color

Can compress the tablet with different layers and different colors.

  1. Multiple Production Capacity

Production capacity can be raised many times under certain conditions.

  1. Safety Protection

If some abnormal condition occurs,it will stop immediately and minimize its negative effects.

Agriculture:Feed block, fertilizer tablets, animal food, animal salt lick
Electronics Batteries:Thermistor, integrated circuit components, carboniferous brush films...
Health Products:calcium, propolis tablets, effervescent tablets, bath salts tablets...
Chemical:disinfection tablets, insect repellent films, camphor ball, detergents, fragrances, catalysts, metallurgy powder, glass powder, ceramic powder products, art powder, sand round block, magnetic materials...

Before-sale Service
1. Professional consultation about each type of machine is provided.
2. Free testing service is offered to help customers purchase suitable machine.
3. Warm welcome to visit and evaluate our factory.
4. To press heavy block like animal salt block, licks, we need larger pressure, below rules are for your reference:
A. We would like to recommend machines based on your requirements as following:
1. Product name
2. Products' size and shape
3. Products' weight
4. Capacity
B. We will design, customize and make dies for you.
After-sale Service
1. All the machines will be adjusted and tested before shipping.
2. Installing,debugging and training to workers are all offered, after customers receiving our tablet press machine.
