|Place of Origin:||Jiangsu, China|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 set|
|Packaging Details:||Wooden case|
|Delivery Time:||35-65 working days|
|Payment Terms:||TT, LC|
|Working Pressure:||≤60T||Filling Depth:||≤100mm|
|Product Name:||Feed Hydraulic Tablet Press MachineDesiccant Pharmaceutical Tablet Press Machine||Application:||Wax Press|
|Product Mold:||Multi-cavity Mould||Apply To Shape:||Round,square,or Special-shaped|
|Standard:||BV||Type:||Hydraulic Tablet Press|
pill compressor machine,
tablet pill press machine
Desiccant Pharmaceutical Tablet Press Machine
Hydraulic machine is our factory newly developed automatic tabletpressmachine,which can compress granular, powder-like material into a variety of general and special-shaped pieces. It is suitable for large-scale repression of products which require high-density, while a multi-chip module can be used for large-scale production industries, equipment, high precision, easy to learn mold replacement and installation. High degree of automation. All actions by the microcomputer PLC control, continuous automatic. Can be properly adjusted to suppress the time, pressure, product thickness.
Our company has been engaged in the research,development and manufacture of non-standard tablet press machine. Our tablet press machine have broad scope of application. At the same time, offer molding manufacturing service. We have accumulated a lot of material tablet compressing experience. Besides offering tablet press machine and mould, we also can give some technical support on tablet press machine & mould for customers.
After customer received tablet press machine, we will arrange our technician go to your factory to help you debug the machine and also train your workers how to use it. The warranty for this machine will be one year, we will provide vulnerable parts and door-to-door service by free within one year.
The entire hydraulic system imported from Taiwan, Higher stability, so it avoid oil leaking and polluting, It also can ensure the pressure is enough, and action is synchronized for continuous. Working part and the separation of part of the hydraulic system is independent, non-polluting, automatic heated, so it can make the machine more durable.
|Production Capacity||5-7molds/min(the actual speed according to product process requirement)|
|Working Pressure||≤60T(1. step-less adjustment 2. can be bidirectional compress)|
|Working Stroke||Up stroke≤250mm,down strokes≤100mm(1. step-less adjustment 2. Customized based on customer’s request. )|
|Filling Depth||≤100mm(1. step-less adjustment 2. Customized based on customer’s request. )|
|Product Mould||Customized according to the tablet features(Multi-cavity Mould)|
|Apply to Shape||Round, square, or special-shaped(suitable for a variety of shapes)|
|Motor Power||7. 5kw 11kw(Servo)|
Descriptions and Advantage:
Each action can be set separately. Special material tablet forming can be solved by precise control and flexible technology.
Production debugging is operated through PLC touch screen, which can cut the cumbersome process in great scope and make the operation more easily.
The filling method and dosage can be intelligently controlled, rapidly and stably, which can save much time and labor.
Oil cylinder working area and mechanical working area are Mutual independence, preventing oil pollution.
Technology and Advantage:
Protecting the compressed tablet well,which are damaged by improper mould forces in the course of production.
Uniform density of the compressed tablet can be ensured through special technology.
Can compress the tablet with different layers and different colors.
Production capacity can be raised many times under certain conditions.
If some abnormal condition occurs,it will stop immediately and minimize its negative effects.
|Agriculture:||Feed block, fertilizer tablets, animal food, animal salt lick|
|Electronics Batteries:||Thermistor, integrated circuit components, carboniferous brush films...|
|Health Products:||calcium, propolis tablets, effervescent tablets, bath salts tablets...|
|Chemical:||disinfection tablets, insect repellent films, camphor ball, detergents, fragrances, catalysts, metallurgy powder, glass powder, ceramic powder products, art powder, sand round block, magnetic materials...|
1. Professional consultation about each type of machine is provided.
2. Free testing service is offered to help customers purchase suitable machine.
3. Warm welcome to visit and evaluate our factory.
4. To press heavy block like animal salt block, licks, we need larger pressure, below rules are for your reference:
A. We would like to recommend machines based on your requirements as following:
1. Product name
2. Products' size and shape
3. Products' weight
B. We will design, customize and make dies for you.
1. All the machines will be adjusted and tested before shipping.
2. Installing,debugging and training to workers are all offered, after customers receiving our tablet press machine.
